| Size/Weight | 113×103×45(mm)/335g (including the paper roll and battery) | |||||||
| Printing Method | Thermal Line | |||||||
| Printing Width | 72mm | |||||||
| Paper Width | 80mm | |||||||
| Resolution | 203dpi(8 dot/mm) | |||||||
| Printing Speed | 75 mm/s | |||||||
| Dot /Line: | 576 dots/line | |||||||
| Print Font | ASCII Font A: 12×24/ASCII Font B: 9×17/Chinese: 24×24 | |||||||
| Characters Per Line | Font A: 48/Font B: 64/Chinese: 24 | |||||||
| Rolling Paper Diameter: | ￠40(max)X80mm | |||||||
| Paper Feeding Method: | Easy paper loading | |||||||
| Barcode Type: | CODE39/EAN-13/EAN-8/CODABAR/CODE93/ITF /QR/PDF417 | |||||||
| MCBF: | 5 Million Lines | |||||||
| Print Head Lifespan: | 50 km | |||||||
| Interface: | Bluetooth(BT4.0&BLE)/WiFi/USB/RS232 | |||||||
| Paper Out Alarm: | Support | |||||||
| Printing Command: | ESC/POS | |||||||
|
Battery
|
2000 mAh rechargeable li-ion battery | |||||||
| 500+ times lifespan | ||||||||
| Continuously working for 3 hours or 100m | ||||||||
| 4-6 hours' charging time | ||||||||
| Power Supply: | USB/Power adapter/mobile power charging | |||||||
| Power Alarm: |
Battery need to be charged or changed when battery light turns off and red light
turns on |
|||||||
|
Environment Parameters:
|
Working temperature: -10℃～ 50℃ | |||||||
| Working humidity: 20% ～ 85% | ||||||||
| Storing temperature : -20℃ ～ 70℃ | ||||||||
| Storing humidity: 5% ～ 95% | ||||||||
