System Parameters
|
CPU | ARM Cortex A7, 1.2GHz |
| Operating system | Android 5.1 | |
|
Memory
|
ROM 8GB
RAM 1GB |
|
| Touch Screen | 5.0 inches IPS | |
| Keypad | One power key, one physical function key, in-screen virtual touch keys | |
| Battery | 7.4V 3600mAh | |
|
Functional Configuration
|
Printer | 2 inches line thermal printer |
| Communication | WCDMA 2G/3g WiFi Bluetooth | |
| Camera | 5 mega-pixel | |
| Barcode reader | 1D/2D barcode | |
| GPS | Support | |
|
Payment
|
Non-contact Card | 13.56MHz, ISO/IEC 14443 Type A/B, accord with QPBOC standard |
| Magnetic Strip Card | Support 1/2/3 magnetic track, bi-directional swiping | |
| IC Card | one user slot, support 1.8V/3V/5V card | |
|
Interface
|
SIM | one user slot |
| SAM | two user slot | |
| USB | 1 MICRO USB+1 MINI USB | |
| DC |
Input: 110V～240V AC/50～60Hz
Output: 5V DC/2A |
|
| Certificate |
CCC
PBOC Level 1&2 qPBOC Level 1&2 EMV Level 1& 2 EMV Contectless Level 1 |
|
| Size | 191mm×80mm×46mm | |
